Description
Specification (ASA5506-K9)
ASA5506-K9 Specifications |
|
|
Type |
Cisco ASA 5506-X w/ FirePOWER Services |
|
Throughput: Application Control (AVC) |
250 Mbps |
|
Throughput: Application Control (AVC) and IPS |
125 Mbps |
|
Maximum concurrent sessions |
20,000; 50000 |
|
Maximum New Connections per second |
5,000 |
|
Supported applications |
More than 3,000 |
|
URL categories |
80+ |
|
Number of URLs categorized |
More than 280 million |
|
Centralized configuration, logging, monitoring, and reporting |
Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
|
On-Device Management |
ASDM (version 7.3 or higher required) |
|
Feature |
Cisco ASA 5506-X w/ FirePOWER Services |
|
Stateful inspection throughput (maximum1) |
750 Mbps |
|
Stateful inspection throughput (multiprotocol2) |
300 Mbps |
|
Triple Data Encryption Standard/ |
100 Mbps |
|
Users/nodes |
Unlimited |
|
IPsec site-to-site VPN peers |
10; 50 |
|
Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections5 |
50 |
|
Virtual interfaces (VLANs) |
5; 30 |
|
Security contexts5(included; maximum) |
N/A |
|
High availability |
Requires Security Plus License; Active/ |
|
Integrated Wireless Access Point (See Cisco AP 702 datasheet for WiFi technical details) |
N/A |
|
Expansion slot |
N/A |
|
User-accessible Flash slot |
No |
|
USB 2.0 ports |
USB port type ‘A’, High Speed 2.0 |
|
Integrated I/O |
8 x 1 Gigabit Ethernet (GE) |
|
Expansion I/O |
N/A |
|
Dedicated management port |
Yes (To be shared with FirePOWER Services), 10/100/1000 |
|
Serial ports |
1 RJ-45 and Mini USB console |
|
Solid-state drive |
50 GB mSata |
|
Memory |
4 GB |
|
System flash |
8 GB |
|
System bus |
Multibus architecture |
|
Temperature |
32 to 104°F (0 to 40 °C) |
|
Relative humidity |
90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 10,000 ft (3048 m) |
|
Acoustic |
Fanless |
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4572 m) |
|
AC range line voltage |
External, 90 to 240 volts alternating current (VAC) |
|
AC normal line voltage |
90 to 240 VAC |
|
AC current |
N/A |
|
AC frequency |
50/60 Hz |
|
Dual-power supplies |
None |
|
DC domestic line voltage |
N/A |
|
DC international line voltage |
N/A |
|
DC current |
N/A |
|
Steady state |
12V @2.5A |
|
Maximum |
12V @ 5A |
|
Maximum |
103 British thermal units (Btu)/hr |
|
Form factor |
Desktop, rack mountable |
|
Dimensions (H x W x D) |
1.72 x 7.871 x 9.23 in. |
|
(4.369 x 19.992 x 23.444 cm) |
|
|
Weight (with AC power supply) |
4 lb (1.82 kg) |
