Description
Specification (ASA5515-K9)
ASA5515-K9 Specifications |
|
| Type | Cisco ASA 5515-X w/ FirePOWER Services |
| Throughput:
Application Control (AVC) |
500 Mbps |
| Throughput:
Application Control (AVC) and IPS |
250 Mbps |
| Maximum concurrent sessions | 250,000 |
| Maximum New Connections per second | 15,000 |
| Supported applications | More than 3,000 |
| URL categories | 80+ |
| Number of URLs categorized | More than 280 million |
| Centralized configuration, logging, monitoring, and reporting | Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
| On-Device Management | ASDM |
| Feature | Cisco ASA 5515-X w/ FirePOWER Services |
| Stateful inspection throughput (maximum1) | 1.2 Gbps |
| Stateful inspection throughput (multiprotocol2) | 600 Mbps |
| Triple Data Encryption Standard/ Advanced Encryption Standard (3DES/AES) VPN throughput3 |
250 Mbps |
| Users/nodes | Unlimited |
| IPsec site-to-site VPN peers | 250 |
| Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections5 | 250 |
| Virtual interfaces (VLANs) | 100 |
| Security contexts5(included; maximum) | 2.5 |
| High availability | Active/ Active and Active/ Standby |
| Integrated Wireless Access Point
(See Cisco AP 702 datasheet for WiFi technical details) |
N/A |
| Expansion slot | 1 interface card |
| User-accessible Flash slot | No |
| USB 2.0 ports | 2 |
| Integrated I/O | 6 GE copper |
| Expansion I/O | |
| 6 GE copper or 6 GE SFP | |
| Dedicated management port | Yes (1 GE) |
| Serial ports | 1 RJ-45 console |
| Solid-state drive | 1 slot, 120 GB MLC SED |
| Memory | 8 GB |
| System flash | 8 GB |
| System bus | Multibus architecture |
| Temperature | 23 to 104°F (-5 to 40°C) |
| Relative humidity | 10 to 90 percent noncondensing |
| Altitude | Designed and tested for 0 to 15,000 ft (4572 m) |
| Acoustic noise |
64.2 dBA max |
| Temperature | -13 to 158ºF (-25 to 70ºC) |
| Relative humidity | 10 to 90 percent noncondensing |
| Altitude | Designed and tested for 0 to 15,000 ft (4570 m) |
| AC range line voltage | 100 to 240 VAC |
| AC normal line voltage | 100 to 240 VAC |
| AC current | 4.85A |
| AC frequency | 50/60 Hz |
| Dual-power supplies | None |
| DC domestic line voltage | -40.5 to 56 VDC (-48 VDC nominal) |
| DC international line voltage | -55 to -72 VDC
(-60 VDC nominal) |
| DC current | 15A (maximum input) |
| Steady state | 65W |
| Maximum peak |
70W |
| Maximum heat dissipation |
239 Btu/hr |
| Form factor | 1RU, 19-in. rack-mountable |
| Dimensions
(H x W x D) |
1.67 x 16.7 x 15.6 in. |
| (4.24 x 42.9 x 39.5 cm) | |
| Weight (with AC power supply) | 13.39 lb (6.07 kg) |
