Description
Quick Specs
| Product Code | C9300L-48T-4X-10A |
| Product Description | C9300L 48p Data, Netw Adv,4x10G Uplink |
| Total 10/100/1000 or Multigigabit copper ports | 48 Data |
| Uplink Configuration | 4x 10G fixed uplinks |
| Default AC power supply | 350W |
| Available PoE power | N/A |
| Dimensions (H x W x D) | 1.73 X 17.5 X 16.1 Inches |
Compare to Similar Items
|
Product Code |
C9300-48S-A | C9300L-48T-4X-10A |
|
Product Description |
Catalyst 9300 48 GE SFP Ports, modular uplink Switch | C9300L 48p Data, Netw Adv,4x10G Uplink |
|
Total 10/100/1000 or Multigigabit copper ports |
48x 1G SFP | 48 Data |
| Uplink Configuration | Modular Uplinks | 4x 10G fixed uplinks |
| Default AC power supply | 715W AC | 350W |
| Available PoE power | N/A | N/A |
| Dimensions (H x W x D) | 1.73 x 17.5 x 17.7Inches | 1.73 X 17.5 X 16.1 Inches |
C9300L-48T-4X-10A Specification
C9300L-48T-4X-10A Specification |
|
| Product Code | C9300L-48T-4X-10A |
| Product Description | C9300L 48p Data, Netw Adv,4x10G Uplink |
| Total 10/100/1000 or Multigigabit copper ports | 48 Data |
| Uplink Configuration | 4x 10G fixed uplinks |
| Default AC power supply | 350W |
| Available PoE power | N/A |
| Dimensions (H x W x D) | 1.73 X 17.5 X 16.1 Inches |
| Cisco StackWise-480 | Yes |
| Cisco StackPower | Yes |
| Default power supply | PWR-C1-350WAC-P |
| Switching capacity | 176 Gbps |
| Stacking bandwidth | 496 Gbps |
| Forwarding rate | 130.95 Mpps |
| Total number of MAC addresses | 32,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 32,000 (24,000 direct routes and 8000 indirect routes) |
| IPv4 routing entries | 32,000 |
| IPv6 routing entries | 16,000 |
| Multicast routing scale | 8000 |
| QoS scale entries | 5120 |
| ACL scale entries | 5120 |
| Packet buffer per SKU | 16 MB buffer for 24- or 48-port Gigabit Ethernet modelst |
| FNF entries | 64,000 flow on 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB |
| Flash | 16 GB |
| VLAN IDs | 4094 |
| Total Switched Virtual Interfaces (SVIs) | 1000 |
| Jumbo frames | 9198 bytes |
| Total routed ports Catalyst per 9300 Series stack | 416 |
| Wireless bandwidth per switch | Up to 96 Gbps on 48-port Gigabit Ethernet model |
| Mean time between failures – MTBF (hours) | 380,080 |
| Safety certifications
|
•UL 60950-1
•CAN/CSA-C222.2 No. 60950-1 •EN 60950-1 •IEC 60950-1 •AS/NZS 60950.1 •IEEE 802.3 |
| Electromagnetic emissions certifications | •47 CFR Part 15
•CISPR22 Class A •EN 300 386 V1.6.1 •EN 55022 Class A •EN 55032 Class A •CISPR 32 Class A •EN61000-3-2 •EN61000-3-3 •ICES-003 Class A •TCVN 7189 Class A •V-3 Class A •CISPR24 •EN 300 386 •EN55024 •TCVN 7317 • V-2/2015.04 •V-3/2015.04 •CNS13438 •KN32 •KN35 •IEC 61000-6-1 •EN 61000-6-1 |
| Environmental | Reduction of Hazardous Substances
(ROHS) 5 |
